JAZZY EVO 613

Breaking down barriers with the Jazzy EVO 613 Power Chair series

The Jazzy® EVO 613 and Jazzy® EVO 613Li measure in at an impressive 22 inches wide at the base and offer a 22-inch turning radius. Not only is it one of the most powerful power wheelchairs on the market, but it’s also one of the narrowest and most maneuverable.

The Jazzy EVO 613 series gives you all the best that Pride has to offer with patented Active-Trac Suspension and exclusive Mid-Wheel 6® Technology that provide you with a smoother, stable ride.

And it does all that while pushing the limits of mileage and speed capabilities. A single charge can carry you up to 21 miles with the lithium battery, and top speeds up to 5.1 mph.

The Jazzy EVO 613 series of power wheelchairs with lithium batteries represent a philosophy we share here at Pride Mobility. If you’re not constantly improving, ever innovating, and pushing boundaries, you might as well fall behind.

Key Features
300 lb. weight capacity
Narrow base width of only 22″
Maximum speed up to 5.1 mph
3″ Ground clearance for
13″ solid drive tires
Per charge range up to 17 miles with U1 SLA batteries and up to 21 miles with lithium ion (200 lbs.)
Mid-wheel 6® Technology offers tight turning radius around doorways and corners
Pride’s patented Active-Trac (ATX) Suspension ensures a smooth ride experience over uneven surfaces
Memory foam high-back seat with single seat post allows the user to swivel
Available depth-adjustable seat sizes: 16″ W x16″-18″ D, 18″ W x 18″-20″ D, 20″ W x 18″-20″
Height, width, and angle adjustable armrests
Flip-up, height, angle, and depth adjustable foot platform
Removable matte-finish color-through shrouds
HCPCS Code: Group 2: Standard (K0822/K0823)
Specifications
Model: Jazzy® EVO 613/ Jazzy® EVO 613 Li
Weight Capacity: 300 lb.
Turning Radius3: 22 in.
Width3: 22 in.
Length3: 41 in. w/footplate 35 in. w/o footplate
Maximum Speed2: Up to 5.1 mph
Ground Clearance3: 3 in. at motor bracket
Front Wheels: 5 in. solid
Drive Wheels: 13 in. solid
Rear Wheels: 5 in. casters
Drivetrain: Two motor, in-line, mid-wheel drive
Braking System: Regenerative and electro-mechanical
Suspension Type: Active-Trac® (ATX)
Standard Seat Sizes: High-back Black vinyl 16 x16 -18 in., 18 x18 -20 in., 20 x18 -20 in.
Seat-to-Floor Range: 19.75 in.-21.25 in.
Seat Weight(s)3: 46 lb. (16 in.), 48 lb. (18 in.), 50 lb. (20 in.)
Maximum Seat Size: 20 in.-20 in.
Power Elevating Seat: NA
Standard Electronics: 40A, PG GC3
Battery Size(s)4: (2) 12 volt, U-1 or (1) 25V Lithium-iron phosphate
Battery Weight6: (2) U1-23.5 lb. each; (1)Lithium – 18.5 lb.
Battery Charger: 3.5A, off-board
Per Charge Range2,3,5: SLA- up to 14 miles (300 lb.), up to 17.1 miles (200lb.,); Lithium up to 17.6 miles ( 300 lb.), up to 21 miles (200lb.)
Weight of Heaviest Piece7: 94 lb. (base)
Total Weight: 189 lb. . (SLA); 160.5 (Lithium)
HCPCS Code: Group 2: Standard (K0822/K0823)
Warranty: Frame: 5-year limited; Drivetrain: 13-month limited; Electronics: 13-month limited; Batteries: 13-month limited (SLA); 3-year limited (Lithium)
Colors: Black (matte), White (matte), Red (matte), Iceberg Blue (matte), Robin’s Egg Blue (matte), Sugar Plum (matte)
NOTES:
*Pride® FDA Class II Medical Devices are designed to aid individuals with mobility impairments 1Jazzy Power Chairs are FDA class II Medical Devices designed to aid individuals with mobility impairments 2Varies with user weight, terrain type, battery amp-hour(AH), battery charge, battery condition and tire condition. These specifications can be subject to a variance of (+/- 10%). 3Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of (+/* 3%). 4AGM or gel cell type required. 5Tested in accordance with ANSI/RESNA, WC Vol2, section 4 & ISO 7176-4 standards. Results derived from theoretical calculations based on battery specifications and drive system performance. Test conducted at maximum weight capacity. 6Battery weight may vary based on manufacturer. 7Weight includes base, seat and batteries. HCPCS codes provided should not be considered as legal advice and do not guarantee reimbursement. DME providers are responsible for determining appropriate billing codes when submitting for insurance reimbursement The information contained herein is correct at time of publication; we reserve the right to alter specifications without prior notice. All specifications subject to change without notice. The information contained herein is correct at the time of publication, we reserve the right to alter specifications without prior notice. Speed and range vary with user weight, terrain type, battery charge, battery condition and tire pressure. Due to manufacturing tolerances and continual product improvement, length, width, turning radius and ground clearance can be subject to variance of + or 3-%. Special order seats or non-standard dimensions will not be fold-flat and depth-adjustable.
